- Product Model NDR-120-12
- Brand Antaira Technologies
- RoHS 0
- Description AC/DC CONVERTER 2X12V 120W
- Classification ac-dc-converters
-
PDF
Technical Details
- Power (Watts) 120W
- Features Adjustable Output, DC Input Capable, Universal Input
- Size / Dimension 4.47" L x 1.57" W x 4.93" H (113.5mm x 40.0mm x 125.2mm)
- Mounting Type DIN Rail
- Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
- Type Enclosed
- Operating Temperature -20°C ~ 70°C (With Derating)
- Applications Industrial, ITE (Commercial)
- Approval Agency CB, CE, cULus, EAC, TUV, UKCA
- Efficiency 85.5%
- Voltage - Output 1 12V
- Voltage - Output 2 12V
- Number of Outputs 1
- Voltage - Isolation 3 kV
- Standard Number 62368-1; UL 508
- Current - Output 1 10 A
