- Product Model LOF750-20B48
- Brand Mornsun
- RoHS 1
- Description AC/DC CONVERTER 48V 451W
- Classification ac-dc-converters
-
PDF
Inventory:1519
Technical Details
- Power (Watts) 451W (749W Forced Air)
- Features Adjustable Output, PFC, Universal Input
- Size / Dimension 5.00" L x 3.00" W x 1.69" H (127.0mm x 76.2mm x 43.0mm)
- Mounting Type Chassis Mount
- Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
- Type Open Frame
- Operating Temperature -40°C ~ 70°C (With Derating)
- Applications Household Appliances, ITE (Commercial), Medical
- Efficiency 95%
- Voltage - Output 1 48V
- Minimum Load Required No
- Number of Outputs 1
- Voltage - Isolation 4 kV
- Standard Number 60335-1; 60601-1; 62368-1
- Current - Output 1 15.6 A
