Technical Details

• Power (Watts) 400W (700W Forced Air)
• Features Adjustable Output, PFC, Universal Input
• Size / Dimension 5.00" L x 3.00" W x 1.69" H (127.0mm x 76.2mm x 43.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
• Type Open Frame
• Operating Temperature -40°C ~ 70°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Efficiency 92%
• Voltage - Output 1 12V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 58.3 A
