Technical Details

• Power (Watts) 250W (400W Forced Air)
• Features Adjustable Output, Baseplate, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input
• Size / Dimension 5.00" L x 3.00" W x 1.52" H (127.0mm x 76.2mm x 38.5mm)
• Mounting Type Chassis Mount
• Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
• Type Open Frame, Conformal Coated
• Operating Temperature -40°C ~ 70°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Laboratory
• Approval Agency CE, cURus, UL
• Efficiency 91%
• Voltage - Output 1 12V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 33.3 A
