Technical Details

• Power (Watts) 202W
• Features Adjustable Output, DC Input Capable, PFC
• Size / Dimension 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 305 VAC, 120 ~ 430 VDC
• Type Enclosed
• Operating Temperature -30°C ~ 70°C (With Derating)
• Applications ITE (Commercial), Industrial
• Approval Agency CE, EN, UKCA, UL
• Efficiency 90%
• Voltage - Output 1 24V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 62368-1
• Current - Output 1 8.4 A
