Technical Details

• Power (Watts) 36W
• Features Adjustable Output, Universal Input
• Size / Dimension 3.90" L x 3.23" W x 1.18" H (99.0mm x 82.0mm x 30.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 264 VAC, 120 ~ 370 VDC
• Type Enclosed
• Operating Temperature -30°C ~ 70°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Industrial
• Approval Agency CE, TUV, UL
• Efficiency 86%
• Voltage - Output 1 12V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 62368-1
• Current - Output 1 3 A
