Technical Details

• Power (Watts) 36W
• Features Adjustable Output, DC Input Capable
• Size / Dimension 3.90" L x 2.56" W x 1.18" H (99.0mm x 65.0mm x 30.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 80 ~ 305 VAC, 100 ~ 430 VDC
• Type Enclosed
• Operating Temperature -40°C ~ 85°C (With Derating)
• Applications Household Appliances, ITE (Commercial)
• Efficiency 87.5%
• Voltage - Output 1 12V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 62368-1
• Current - Output 1 3 A
