Technical Details

• Power (Watts) 26W
• Features Adjustable Output
• Size / Dimension 3.15" L x 2.17" W x 0.98" H (80.0mm x 55.0mm x 25.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 305 VAC, 100 ~ 430 VDC
• Type Enclosed
• Operating Temperature -30°C ~ 70°C (With Derating)
• Applications ITE (Commercial)
• Approval Agency CB, CCC, CE, UL
• Efficiency 87%
• Voltage - Output 1 24V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 62368-1
• Current - Output 1 1.1 A
