Technical Details

• Power (Watts) 156W
• Features Adjustable Output, DC Input Capable, Universal Input
• Size / Dimension 6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 264 VAC, 120 ~ 370 VDC
• Type Enclosed
• Operating Temperature -30°C ~ 70°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Industrial
• Approval Agency CE, EN, UKCA, UL
• Efficiency 88%
• Voltage - Output 1 24V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 62368-1
• Current - Output 1 6.5 A
