Technical Details

• Power (Watts) 300W (499W Forced Air)
• Features Adjustable Output, DC Input Capable, PFC, Universal Input
• Size / Dimension 5.00" L x 3.00" W x 1.08" H (127.0mm x 76.2mm x 27.5mm)
• Mounting Type Chassis Mount
• Voltage - Input 80 ~ 264 VAC, 113 ~ 370 VDC
• Type Open Frame
• Operating Temperature -40°C ~ 80°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Approval Agency CB, CCC, CE, cURus, EAC, TUV, UKCA
• Efficiency 93.5%
• Voltage - Output 1 12V
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 25 A
