Technical Details

• Power (Watts) 15W
• Features Adjustable Output, DC Input Capable, Universal Input
• Size / Dimension 2.50" L x 1.80" W x 0.87" H (63.5mm x 45.7mm x 22.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 264 VAC, 100 ~ 370 VDC
• Type Open Frame
• Operating Temperature -40°C ~ 85°C (With Derating)
• Applications Household Appliances, ITE (Commercial)
• Approval Agency CE, EN
• Efficiency 83%
• Voltage - Output 1 24V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 62368-1
• Current - Output 1 625 mA
