Technical Details

  • Tolerance ±20%
  • Package / Case Radial, Can
  • Size / Dimension 0.492" Dia (12.50mm)
  • Polarization Polar
  • Mounting Type Through Hole
  • Operating Temperature -40°C ~ 105°C
  • Applications General Purpose
  • Lead Spacing 0.197" (5.00mm)
  • Lifetime @ Temp. 6000 Hrs @ 105°C
  • Height - Seated (Max) 1.457" (37.00mm)
  • Capacitance 1.5 mF
  • Voltage - Rated 35 V
  • Impedance 14 mOhms
  • Ripple Current @ Low Frequency 2.07 A @ 120 Hz
  • Ripple Current @ High Frequency 3.45 A @ 100 kHz
