Technical Details

• Power (Watts) 3.192kW
• Features Adjustable Output, I²C Interface, PFC, PMBus™, Remote On/Off, Remote Sense, Standby Output, Universal Input
• Size / Dimension 12.80" L x 4.21" W x 1.61" H (325.1mm x 106.9mm x 40.9mm)
• Mounting Type Chassis Mount
• Voltage - Input 90 ~ 264 VAC, 127 ~ 400 VDC
• Type Enclosed
• Operating Temperature -30°C ~ 70°C (With Derating)
• Applications ITE (Commercial)
• Approval Agency CB, CE, cURus, EAC, TUV, UKCA
• Efficiency 94%
• Voltage - Output 1 380V
• Number of Outputs 1
• Voltage - Isolation 500 V
• Standard Number 62368-1
• Current - Output 1 8.4 A
