Technical Details

• Power (Watts) 1997W
• Features Adjustable Output, DC Input Capable, Load Sharing, PMBus™, Remote On/Off, Remote Sense, Standby Output
• Size / Dimension 12.20" L x 5.00" W x 1.60" H (309.9mm x 127.0mm x 40.6mm)
• Mounting Type Chassis Mount
• Voltage - Input 80 ~ 275 VAC, 120 ~ 300 VDC
• Type Enclosed
• Operating Temperature -20°C ~ 70°C (With Derating)
• Applications ITE (Commercial), Medical
• Efficiency 95%
• Voltage - Output 1 48V
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60601-1; 60950-1; 62368-1
• Current - Output 1 41.6 A
