Technical Details

• Power (Watts) 1522W
• Features Adjustable Output, DC Input Capable, PFC, Remote On/Off, Remote Sense, Universal Input
• Size / Dimension 9.84" L x 5.00" W x 1.59" H (250.0mm x 127.0mm x 40.5mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 264 VAC, 120 ~ 370 VDC
• Type Enclosed
• Operating Temperature -40°C ~ 70°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Approval Agency CE, UKCA, UL
• Efficiency 94%
• Voltage - Output 1 54V
• Voltage - Output 2 5V
• Minimum Load Required No
• Number of Outputs 2
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 28 A
• Current - Output 2 2 A
