Technical Details

• Power (Watts) 600W
• Features Adjustable Output, DC Input Capable, PFC, Remote On/Off, Remote Sense, Standby Output
• Size / Dimension 8.00" L x 4.00" W x 1.60" H (203.2mm x 101.6mm x 40.6mm)
• Mounting Type Chassis Mount
• Voltage - Input 80 ~ 277 VAC, 110 ~ 390 VDC
• Type Enclosed
• Operating Temperature -40°C ~ 70°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Approval Agency BS, CB, CCC, CE, cURus, EN, IEC, UKCA, UL
• Efficiency 94%
• Voltage - Output 1 24V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 25 A
