- Product Model SHP-10K-115
- Brand MEAN WELL
- RoHS 1
- Description AC/DC CONVERTER 115V 10.005KW
- Classification ac-dc-converters
-
PDF
Inventory:1501
Technical Details
- Power (Watts) 10.005kW
- Features Adjustable Output, Load Sharing, PFC, Remote On/Off
- Size / Dimension 17.00" L x 8.31" W x 3.29" H (431.8mm x 211.0mm x 83.5mm)
- Mounting Type Chassis Mount
- Voltage - Input 340 ~ 530 VAC
- Type Enclosed
- Operating Temperature -30°C ~ 70°C (With Derating)
- Applications ITE (Commercial)
- Approval Agency CB, CE, cURus, EAC, TUV, UKCA
- Efficiency 96%
- Voltage - Output 1 115V
- Number of Outputs 1
- Voltage - Isolation 3.75 kV
- Standard Number 62368-1
- Current - Output 1 87 A
