Technical Details

• Power (Watts) 4.992kW
• Features Adjustable Output, I²C Interface, Load Sharing, PFC, PMBus™, Remote On/Off, Remote Sense, Standby Output
• Size / Dimension 13.00" L x 5.00" W x 5.00" H (330.2mm x 127.0mm x 127.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 180 ~ 264 VAC
• Type Enclosed
• Operating Temperature -20°C ~ 70°C
• Applications ITE (Commercial), Medical
• Approval Agency CB, CE, UKCA, UL
• Efficiency 92%
• Voltage - Output 1 48V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60601-1; 62368-1
• Current - Output 1 104 A
