Technical Details

• Power (Watts) 351W
• Features Adjustable Output, PFC
• Size / Dimension 8.66" L x 2.44" W x 1.22" H (220.0mm x 62.0mm x 31.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 305 VAC, 120 ~ 430 VDC
• Type Enclosed
• Operating Temperature -40°C ~ 85°C (With Derating)
• Applications Household Appliances, ITE (Commercial)
• Approval Agency CCC, CE, cURus, EN, UKCA, UL
• Efficiency 94%
• Voltage - Output 1 36V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 62368-1
• Current - Output 1 9.75 A
