Technical Details

• Power (Watts) 250W
• Features Adjustable Output, PFC, Remote On/Off, Standby Output, Universal Input
• Size / Dimension 4.69" L x 2.52" W x 1.56" H (119.2mm x 64.0mm x 39.5mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 264 VAC
• Type Enclosed
• Operating Temperature -20°C ~ 85°C (With Derating)
• Applications ITE (Commercial), Laboratory, Medical
• Approval Agency CE, UKCA
• Efficiency 94%
• Voltage - Output 1 24V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 61010-1; 60601-1; 60950-1; 62368-1
• Current - Output 1 10.41 A
