Technical Details

• Power (Watts) 450W
• Features Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input
• Size / Dimension 5.00" L x 3.00" W x 1.52" H (127.0mm x 76.2mm x 38.5mm)
• Mounting Type Chassis Mount
• Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
• Type Open Frame
• Operating Temperature -40°C ~ 70°C (With Derating)
• Applications ITE (Commercial), Medical
• Approval Agency CE, cURus, UKCA
• Efficiency 93%
• Voltage - Output 1 36V
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1
• Current - Output 1 12.5 A
