Technical Details

• Power (Watts) 40W
• Features Adjustable Output, DC Input Capable, PFC, Universal Input
• Size / Dimension 3.00" L x 2.00" W x 1.16" H (76.2mm x 50.8mm x 29.5mm)
• Mounting Type Chassis Mount
• Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
• Type Open Frame
• Operating Temperature -40°C ~ 70°C (With Derating)
• Applications ITE (Commercial), Medical
• Approval Agency cULus
• Efficiency 83%
• Voltage - Output 1 12V
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60601-1; 62368-1
• Current - Output 1 3.33 A
