Technical Details

• Power (Watts) 982W
• Features Universal Input
• Size / Dimension 5.51" L x 5.91" W x 3.39" H (140.0mm x 150.1mm x 86.1mm)
• Mounting Type Chassis Mount
• Voltage - Input 90 ~ 264 VAC
• Type ATX
• Operating Temperature 0°C ~ 50°C
• Applications ITE (Commercial)
• Approval Agency CB, CCC, CE, cULus, FCC, GS, TUV
• Efficiency 80%
• Voltage - Output 1 3.3V
• Voltage - Output 2 5V
• Voltage - Output 3 12V
• Voltage - Output 4 12V
• Number of Outputs 8
• Voltage - Output 5 12V
• Voltage - Output 6 12V
• Standard Number 60950-1; 62368-1
• Current - Output 1 25 A
• Current - Output 2 25 A
• Current - Output 3 16 A
• Current - Output 4 16 A
• Current - Output 5 16 A
• Current - Output 6 16 A
