Technical Details

• Power (Watts) 225W
• Features Adjustable Output
• Size / Dimension 4.00" L x 2.00" W x 1.22" H (101.6mm x 50.8mm x 31.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 264 VAC
• Type Open Frame
• Operating Temperature -25°C ~ 80°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Approval Agency CB, CE, cETLus, EAC, ETL, UKCA, Ukraine, VCCI, WEEE
• Efficiency 95%
• Voltage - Output 1 24V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 60950-1; 62368-1
• Current - Output 1 9.37 A
