Technical Details

• Power (Watts) 204W
• Features Adjustable Output
• Size / Dimension 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 90 ~ 132 VAC, 180 ~ 264 VAC, 240 ~ 373 VDC
• Type Enclosed, Conformal Coated
• Operating Temperature -30°C ~ 70°C (With Derating)
• Applications Household Appliances, ITE (Commercial)
• Approval Agency CE, CQC
• Efficiency 87.5%
• Voltage - Output 1 12V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 3 kV
• Standard Number 60335-1; 62368-1
• Current - Output 1 17 A
