Technical Details

• Power (Watts) 20W
• Size / Dimension 2.99" L x 1.24" W x 1.29" H (76.0mm x 31.5mm x 32.8mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 305 VAC, 100 ~ 430 VDC
• Type Enclosed
• Operating Temperature -40°C ~ 85°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Approval Agency CE, cURus
• Efficiency 87%
• Voltage - Output 1 24V
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 830 mA
